What is a Coil in an HVAC system?
A coil is an equipment that is used to transfer heat to or from air. It is either heated or cooled by electrical means or by circulating liquid or steam within it. Coils are commonly found in HVAC systems, and they are important components of these systems because they help to regulate the temperature of the air that passes through them.
Condenser coils are used to cool the air, while evaporator coils are used to heat the air.
There are a variety of different types of coils that can be used in HVAC systems, and each type has its own unique set of benefits and drawbacks.
One of the most common types of coils found in HVAC systems is the finned tube coil. This type of coil is so named because it features a series of metal fins that extend out from the tubing. These fins help to increase the surface area of the coil, which in turn allows for more heat transfer. The increased surface area also makes the coil more efficient, which can result in lower energy costs.
Finned tube coils are often used in air handling units and ductwork. They are relatively inexpensive to manufacture and are easy to install. In addition, they are capable of handling a large amount of airflow, making them ideal for use in large HVAC systems.
However, finned tube coils do have some drawbacks. One of the biggest problems with these coils is that they can be very inefficient when it comes to heat transfer. In fact, they can be up to 30% less efficient than other types of coils. Additionally, finned tube coils can be susceptible to corrosion and damage from debris.
Another type of coil that is commonly used in HVAC systems is the plate and fin coil. As its name suggests, this type of coil features a series of metal plates that are attached to a set of fins. This design helps to increase the surface area of the coil, which again allows for more heat transfer. Plate and fin coils are often used in air handling units and ductwork, and they are known for their durability and high heat transfer efficiency.
However, plate and fin coils have some disadvantages.. For one thing, they can be expensive to manufacture. In addition, they can be difficult to install and can require a lot of space. Furthermore, plate and fin coils are not very efficient when it comes to handling high volumes of airflow.
Despite these drawbacks, plate and fin coils are still a popular choice for HVAC systems. They offer many benefits that other types of coils do not, and they are ideal for use in applications where high heat transfer efficiency is important.
Another type of coil is the serpentine coil. This type of coil is so named because it features a series of metal tubing coils that are wrapped around each other. This design helps to increase the surface area of the coil, which in turn allows for more heat transfer. Serpentine coils are often used in air handling units and ductwork, and they are known for their high heat transfer efficiency.
However, serpentine coils have some disadvantages. It’s also important to note that producing them requires a significant amount of money and time. They are also difficult to install, and they require a lot of room. Finally, serpentine coils are less effective at moving a large amount of air.
